Debris Filter and Ball Collector Wuxi Hongxiang Power Auxiliary Equipment Co

Debris Filter with assembly; DN 1800, ST Condenser

MODEL: WNBD-1800-BJS Main Technical Parameters

Design Pressure/Working Pressure: 7.5Bar/6 Bar

Working temperature: 30-33 C°

Flow: 20580 t/h

Filter resistance: ≤ 450mmH20

Filter cartridge aperture: < φ 5 mm

Gear unit reducer: XLEDJ63-1505-1.1

Main material:

Casing:Q235B+Lining wear resistance natural rubber

Internal Equipment Material: S31803 duplex

Motor voltage rating I protection class: 400V/IP54

Electric actuator: IK20

Backwash motor: Y90S-4

PLC protection class: IP54

Dimension (approx.): 3600 x 2700 x 4500 mm

Make: Wuxi Hongxiang Power Auxiliary Equipment Co. China

Ball Collector; DN 1800, ST Condenser

Type: Vertical

Model: WBS-1800-BJS Diameter: φ 1824

Configuration: Motor pushrod with travel trans-control function

-WBDTZ2T Tube body: Q235+Rubber lined

Internal Equipment Material: S31803 duplex

Dimension (approx.): 2000 x 2000 x 2000 mm

Make: Wuxi Hongxiang Power Auxiliary Equipment Co. China

We are competitive source and supplier for Wuxi Hongxiang Power Auxiliary Equipment Co

Products. Country of origin: China If you are looking for
Wuxi Hongxiang Power Auxiliary Equipment Co
Products, welcome to contact us.
